TA-Technix airride kit with air management for BMW 6er Typ E24 (6CS/1)

TA Technix Air Damper Set + TA Technix Air Management with Air Generation Kit

The multi-function display is operated intuitively by means of a freely positionable rotary knob / potentiometer.
The electronic, pressure-based control unit has the option of storing 4 freely configurable bellows pressures / ride heights on an axle-by-axle basis.

With the help of the enclosed operating instructions and the simple menu navigation, the following additional functions, among others, can be used:

- 4 driving heights
- Adjustment of the driving height with ignition on and off (autolevel)
- Axially adjustable excess bellows pressure for optimum adjustment of the ride height
- Protection against foreign use (offers the possibility to lock the system at the desired ride height within 3 seconds)
- maximum as well as minimum tank pressure (adjustable)
- Protection of the on-board power supply through definable upper and lower limits of the on-board voltage
- freely configurable valve times
- Modification of the control unit lighting / ECU lighting
- Minimum pressure of the front and rear axle (falling below the minimum pressure triggers a visual warning signal and is necessary for TÜV registration)

includes:
- Multifunctional display
- Rotary knob / potentiometer including 4 caps in black, red, blue and silver
- anti-reflective foil
- prefabricated wiring harness
- Control unit / ECU
- 3 update cables
- TA Technix 444C compressor in black
- 11,5 litre tank in black
- Electronics set including compressor relay
- Fuse holder including fuse
- 4x 2/2 way valves 1/4 with pressure sensors
- 25 metre 6mm PU hose in black
- all fittings including check valve and safety valve
- water separator
- emergency filling valves

suitable for:
BMW 5 Series, Type E28
incl. M535i + M5
year of construction 1981 - 1987
BMW 6 series, type E24
year of construction 06.1982 - 1989
incl. M635CSI

Approval:

Without approval (not permitted in the area of the STVZO)

Implementation notes:

-

Notes:

With this system, it is not necessary to send in the original front shock absorbers for the conversion. With the help of a welding sleeve and detailed installation instructions included with the order, the conversion of the air shock absorbers can be carried out by a professional garage.

Axle:

-

KeyType number:

227,226,7059,235,234,233,232,231,230,229,228,225,224,223,221,27712,274,7028,273,275,70156,5090,4945,270
