DBA 5000 series Wave Crossed Drilled, Slotted & Dimpled Rotor Only DBA53000.1WXD (2 pcs)

T3 Slot – 48 Precision CNC Machined Slots

Feature: Tri-symmetrical curve slots dampen vibration harmonics and noise

Advantage: A quieter, more responsive, and smoother brake pedal feel

Feature: Increased number of out-gassing exit points for brake pad friction gases

Advantage: Increases the consistency and effectiveness of every brake stop

Feature: Universal slot design

Advantage: Eliminates the need for separate left and right discs

Kangaroo Paw – 144 Diamond and Tear Drop Pillar Ventilation System

Feature: Increased surface area results in greater heat dissipation

Advantage: Minimises brake fade and increases braking effectiveness

Benefit: Prolongs service life for both pads and rotors; reduces mechanical damage and associated costs

XG150 High Carbon Alloyed Iron

Feature: Increased thermal capacity allows the rotor to handle constant extremes of heat over extended periods

Advantage: Minimises warping and cracking

Benefit: Prolongs the service life of the rotor

Thermal Stability Profiling (TSP)

Feature: Special formulation designed to respond to DBA’s TSP process

Advantage: Maintains structural integrity under thermal stress

Benefit: Minimises warping and cracking; extends rotor lifespan

Thermographic Temperature Monitoring (TTM)

Feature: Heat paint markings change colour at specific temperature thresholds

Advantage: Offers a clear visual indication of peak braking temperatures

Feature: Permanent colour change when thresholds are exceeded

Benefit: Helps monitor rotor fatigue, supports proactive replacement, and assists in warranty claims

Paint Protection on Non-Friction Areas

Feature: Corrosion-resistant paint applied to non-friction zones

Advantage: Prevents rust formation

Benefit: Enhances product appearance and long-term value

Technical information:

Diameter [mm]: 390
Thickness [mm]: 36
Disc Vent: Kangaroo Paw
Annulus [mm] (Maximum useable pad width): 72,5
Pitch Circle Diameter (P.C.D.): 215,9
Inside Diameter [mm]: 245
Diameter & Number of Bolt Holes [mm]: 6.4 (x12)
Air Gap [mm]: 17
Offset [mm]: -3,5
Flange Inside Diameter [mm]: 198
Flange Thickness [mm]: 7
Hole Type: Elongated Hole
Stage: Stage 5
Tech Bulletins: Bedding-In Brakes | Motorsport Information
Replacement Nuts: Included

Suitable for:

N/A
