GARRETT 914956-0003 BLOW-OFF VALVE VTA GVB-50A 50 MM BLACK

Description GARRETT 914956-0003 Blow-Off Valve VTA GVB-50A 50 mm Black

The GARRETT 914956-0003 VTA GVB-50A in black is a high-performance 50 mm blow-off valve engineered by Garrett, the creators of G-Series turbochargers and GVW wastegates. Designed for vent-to-atmosphere operation, it ensures maximum airflow and precise boost control. Optimized through CFD testing, this valve achieves a maximum flow of 350 CFM / 0.21 kg/s (GVB-50R) while maintaining exceptional thermal efficiency. A Nomex-reinforced diaphragm ensures long service life, while the plated stem and bushing reduce friction and wear. Supplied as a complete kit, it includes fasteners, springs, fittings, clamps, V-bands, and flanges for straightforward installation.

• CFD-tested design for maximum flow and thermal efficiency
• Replaceable components for extended service life
• Robust construction allows easy diaphragm replacement
• 6061 anodized aluminum actuator cover with billet-machined housing
• Maximum flow: 350 CFM / 0.21 kg/s (GVB-50R)
• Four recirculating outlet adapters available (sold separately)
• Base pressure: 0.7 Bar / 10 PSI (blue and white spring installed)
• Configurable spring settings: 3 / 4 / 6 / 7 / 9 / 10 / 12 / 13 PSI
• Wrought aluminum alloy weld flange
• 17/7 PH stainless steel springs
• Plated stem and bushing for reduced friction and improved wear resistance
• High-temperature Nomex reinforced diaphragm
• Stainless steel fittings and fasteners

Product category: Blow Off Valves
