GARRETT 898344-0001 SPRING VALVE RED FOR WASTEGATE GVW-40

The Garrett 898344-0001 Spring Valve Red is a replacement part for the wastegate Garrett GVW-40. This spring valve is designed to regulate the pressure in the wastegate actuator; which controls the amount of exhaust gas flow to the turbocharger turbine. By regulating the wastegate; the turbocharger can operate more efficiently and effectively. The "Red" spring valve typically denotes a higher pressure rating than other colors; meaning that it will allow for more boost pressure before the wastegate actuator opens and releases exhaust gas. This can result in increased power and performance from the turbocharged engine. However; it is important to ensure that the spring valve is matched appropriately to the specific application and engine requirements to avoid over-boosting or other potential issues. It is recommended to consult with a qualified mechanic or turbocharger specialist for guidance on selecting the appropriate spring valve for your particular application. Technical Data: 17/7 PH stainless steel Max Spring Base Pressure: 1.7 bar | 25 psi (1:1 backpressure ratio) Minimum Spring Base Pressure: 0.2 bar | 3 psi (1:1 backpressure ratio) Spring - suit Garret GVW-40

Product category: Wastegate
